Tau estimate for Reduced Rank Regression

Fits a reduced-rank regression (RRR) model (for a description, see Izenman(2008)) with a robust procedure that can resist the presence of outliers. It computes tau type estimates, see Bergesio et al. (2020). It fits also a multivariate linear model (MLM) without rank restriction if the rank is chosen properly.

tauRRR(yy, XX, d, efficiency = 0.90)

Arguments

yy	vector of response variables, $n x p$ matrix, each row is a response vector
XX	vector of covariates in the multivariate regression problem. Is a $n x r$ matrix, each row is the corresponding covariate vector
d	rank of coefficient matrix. If `d`$ = min(p,r)$, this routine produces robust multivariate linear regression estimators. If `d`$ < min(p,r)$, this routine produces a reduced rank regression model, with arbitrary covariance of errors
efficiency	efficiency of the robust estimators, 0.90 by default

Details

We consider the multivariate linear reduced rank regression (RRR) model given by $$Y = \mu + ABX + \epsilon,$$ where the variables are

$Y$ is a p x 1 observed response vector
$X$ is a r x 1 observed covariates vector
$\epsilon$ is unobserved p dimensional vector of errors

and the unknown parameters (to be estimated) are

$\mu$ a p x 1 vector of intercepts
A is a full-rank p x d matrix
B is a full-rank d x r matrix
cov($\epsilon$), the p x p covariance matrix of errors $\epsilon$,

Both coefficient matrices A and B are not unique, but their product p x r matrix C = AB is unique. The rank of C is d $\le min(p,r)$. The notation refers to Izenman (2008).

Value

List with the following components, of the RRR model described above

tau-estimator for intercept vector

RRRcoef

tau-estimator for the coefficient p x r matrix C of rank d

tau-estimator for A, a full-rank p x d matrix

tau-estimator for B, a full-rank d x r matrix

cov.error

tau-estimator for the covariance matrix of errors, cov($\epsilon$)

References

Izenman, A. J. (2008). Modern multivariate statistical techniques. Regression, classification and manifold learning, New York: Springer.

Bergesio, A., Szretter Noste, M. E. and Yohai, V. J. (2020). A robust proposal of estimation for the sufficient dimension reduction problem

Examples


# We work with Example 6.3.3, Chemical Composition of Tobacco, from
# Izenman (2008). Dataset available in \link[rrr]{tobacco} or in
# \url{https://astro.temple.edu/~alan/tobacco.txt}

library(rrr)
#>
#> Attaching package: ‘rrr’
#> The following object is masked from ‘package:stats’:
#>
#>     residuals
data(tobacco)

XX = as.matrix(tobacco[,4:9])  # covariates
yy = as.matrix(tobacco[,1:3])  # response vector

###############################
# RRR model with d=2
###############################
# robust MLM fit
robustRRR2 = tauRRR(yy, XX, d=2)
#> maximun iterations are reached

# maximum likelihood MLM, with arbitrary covariance of errors matrix
maxliRRR2 = MLE(yy, XX, d=2)


###############################
# robust MLM fit
###############################
robustMLM = tauRRR(yy, XX, d=3)

# classical MLM, with covariance of errors a multiple of identity
classicalMLM = lm(yy ~ XX)

# maximum likelihood MLM, with arbitrary covariance of errors matrix
maxlikMLM = MLE(yy, XX, d=3)

# to show that the three of them agree, we can do any of the following

# 1. Verify they span the same column space
library(pracma)
angle_AB(orth(robustMLM$RRRcoef),orth(t(classicalMLM$coefficients[2:7,])))
#> [1] 0.000000e+00 0.000000e+00 8.537736e-07
# equivalently
angle_AB(robustMLM$AA ,orth(t(classicalMLM$coefficients[2:7,])))
#> [1] 0.000000e+00 1.478779e-06 9.697005e-06
angle_AB(robustMLM$AA,maxlikMLM$gamma)
#> [1] 0.000000e+00 1.707547e-06 9.391510e-06

# 2. Plot coefficients estimated by every method
plot(robustMLM$RRRcoef,t(classicalMLM$coefficients[2:7,]))
abline(0,1)

points(t(classicalMLM$coefficients[2:7,]),maxlikMLM$gamma%*%maxlikMLM$beta,col="red")

# 3. Compute maximum absolute difference in coefficients estimated by every method
max(abs(t(classicalMLM$coefficients[2:7,])-maxlikMLM$gamma%*%maxlikMLM$beta))
#> [1] 8.881784e-14
max(abs(t(classicalMLM$coefficients[2:7,])-robustMLM$RRRcoef))
#> [1] 1.838174
